IS 2062 Grade Certified
High tensile structural strength, superior weldability & bendability.
Extensive Yard Inventory
6mm to 100mm solid square bars in prime stock in Raipur.
Wholesale Mill Rates
Competitive commercial pricing with transparent weighbridge billing.
PAN-India Dispatch
Prompt multi-axle freight loading with on-time delivery tracking.
Mild Steel Square Bars (MS Square Bar) Dimensions & Weight Table
Complete weight specifications table per meter for Mild Steel Square Bars (MS Square Bar / MS Square Bars / IS 1732 / IS 2062 grade).
Mild Steel Square Bars Size & Weight Chart
IS 1732 Standard Sizes| Square Bar Size (Side mm) | Category | Side Width (mm) | Side Height (mm) | Weight in Kgs / Mtr (kg/m) | Instant Quote |
|---|---|---|---|---|---|
| 6 mm | Light Bar | 6 mm | 6 mm | 0.28 | |
| 8 mm | Light Bar | 8 mm | 8 mm | 0.50 | |
| 10 mm | Light Bar | 10 mm | 10 mm | 0.79 | |
| 12 mm | Standard Bar | 12 mm | 12 mm | 1.13 | |
| 14 mm | Standard Bar | 14 mm | 14 mm | 1.54 | |
| 16 mm | Standard Bar | 16 mm | 16 mm | 2.01 | |
| 18 mm | Standard Bar | 18 mm | 18 mm | 2.54 | |
| 20 mm | Standard Bar | 20 mm | 20 mm | 3.14 | |
| 22 mm | Standard Bar | 22 mm | 22 mm | 3.80 | |
| 25 mm | Standard Bar | 25 mm | 25 mm | 4.91 | |
| 28 mm | Medium Bar | 28 mm | 28 mm | 6.15 | |
| 32 mm | Medium Bar | 32 mm | 32 mm | 8.04 | |
| 36 mm | Medium Bar | 36 mm | 36 mm | 10.18 | |
| 40 mm | Medium Bar | 40 mm | 40 mm | 12.56 | |
| 45 mm | Medium Bar | 45 mm | 45 mm | 15.90 | |
| 50 mm | Medium Bar | 50 mm | 50 mm | 19.63 | |
| 55 mm | Heavy Bar | 55 mm | 55 mm | 23.74 | |
| 60 mm | Heavy Bar | 60 mm | 60 mm | 28.26 | |
| 65 mm | Heavy Bar | 65 mm | 65 mm | 33.17 | |
| 70 mm | Heavy Bar | 70 mm | 70 mm | 38.47 | |
| 75 mm | Heavy Bar | 75 mm | 75 mm | 44.16 | |
| 80 mm | Heavy Bar | 80 mm | 80 mm | 50.24 | |
| 90 mm | Heavy Bar | 90 mm | 90 mm | 63.59 | |
| 100 mm | Heavy Bar | 100 mm | 100 mm | 78.50 |
What are Mild Steel Square Bars (MS Square Bars)?
Mild Steel Square Bars (MS Square Bar / Solid Square Rod) are solid-section steel bars with a perfect square cross-section, hot-rolled from low-carbon structural steel billets in accordance with Indian Standards IS 2062 Grade E250 / IS 1732. Due to their uniform cross-section, high dimensional accuracy, and excellent machinability, MS Square Bars are widely used in shaft manufacturing, gate fabrication, grille making, keyways, and structural reinforcement across India.
At mssquarebar.com, we stock and distribute a comprehensive inventory of MS Square Bars ranging from light solid bars (6mm, 8mm, 10mm) to heavy square bars (75mm, 80mm, 100mm) in standard rolling lengths of 6.0 to 12.0 meters with customized shearing and cutting options available.
High Weldability
Low carbon equivalent (< 0.23% C) ensures effortless manual arc, MIG, and submerged arc welding without pre-heating.
Easy Machinability
Smooth rolling surface ideal for punching, drilling, bending, shearing, cold forming, and galvanizing.
Precise Weight Tolerance
Strict conformance with IS 1732 rolling tolerances ensuring exact kg/meter weight accuracy for structural engineering.
Corrosion Protection
Exceptional surface finish suitable for hot-dip galvanizing, electroplating, epoxy primer, and anti-corrosive coatings.
Common Industrial Applications of MS Square Bars
Mild Steel Square Bars are widely utilized across multiple industrial sectors due to their strength-to-weight ratio and ease of jointing:
Structural Fabrication & PEB
Used for base plates, gusset plates, bracings, connection cleats, purlin ties, and structural framing in pre-engineered buildings.
Industrial Walkways & Gratings
Essential bearing and cross bars for electro-forged metal gratings, catwalks, stair treads, and drain covers.
Electrical Earthing Strips
Galvanized MS Square Bars (GI Flats like 25x3, 50x6, 75x10mm) used as grounding strips for sub-stations, transformer yards, and lightning protection.
Automotive & Engineering
Manufacturing of leaf spring clamps, chassis brackets, agricultural trailers, industrial gates, grills, and machinery chassis.
Frequently Asked Questions
Find answers to commonly asked questions about Mild Steel Square Bars orders, rolling tolerances, and deliveries.
MS Square Bars are typically supplied in standard commercial lengths of 5.5 to 6.5 meters (approx 6 meters) and 10 to 12 meters. We can also provide customized cut-to-length square bars and sheared plates upon advance order confirmation.
We supply Mild Steel Square Bars conforming to IS 2062 Grade E250 (Fe 410 WA/WB), IS 1732, as well as high-tensile E350 grades and commercial rolling grades as per client engineering specifications with full Mill Test Certificates (MTC).
We accommodate both retail fabricators (bundle quantities starting from 500 kg to 1 Ton) and large-scale infrastructure contractors with multi-axle trailer loads (25 to 40 Metric Tons per dispatch).
Billing is strictly based on certified electronic weighbridge gross and tare weight slips generated at the time of truck loading at our Raipur stockyard, ensuring 100% transparency.
Yes, we offer complete logistics support with trusted freight carriers for prompt dispatch across Chhattisgarh, Maharashtra, Madhya Pradesh, Odisha, Telangana, Andhra Pradesh, Gujarat, and all major industrial belts across India.
A Venture of JMD TRADING CO.
mssquarebar.com is backed by the comprehensive warehousing, nationwide logistics network, and decades of industrial steel distribution expertise of JMD TRADING CO. — Central India's leading stockist, supplier, and trading enterprise based in Raipur, Chhattisgarh.
MS Square Bars (Mild Steel Square Bar)
IS 2062 Grade E250 / IS 1732 solid square bars from 6mm to 100mm in ready stock.
HR Plates & Sheets
IS 2062 E250 / E350, High Tensile, Boiler Quality & Chequered Plates (2mm to 100+mm).
MS Channels (ISMC)
Prime structural channels from 75x40mm up to 400x100mm with certified test reports.
MS Angles (ISA)
Equal and Unequal structural angles for transmission towers, PEB sheds, and fabrications.
MS Beams & Joists (ISMB)
Heavy structural I-Beams (100mm to 600mm) for bridge girders, heavy engineering & columns.
MS Pipes & Hollow Sections
Round ERW pipes, Square & Rectangular Hollow Sections (SHS/RHS) in all schedule sizes.
Explore Complete Structural Steel Inventory
Looking for a complete Bill of Materials (BOM) package or factory-direct mill rates for multi-product dispatches?
Ready to Place Your Order for Mild Steel Square Bars?
Connect directly with our sales team for instant wholesale price quotes, project discounts, and fast delivery of Mild Steel Square Bars (MS Square Bar / MS Square Bars).
